10CABLE & ACCESSORIESTogether we GENERATE VALUESurface-Mounted Junction BoxesAP45 is equipped with 8 self-sealing membrane cable entries abbfor cables up to %u00d8 17 mm and 4 for cables up to %u00d8 10 mm. The membranes enable easy cable installation by simply inserting the stripped ends through the inlets. The box can be furnished with the strain-reliefs AS9.10.Junction Box 105x43mm, IP65Part No. Description2TKA00005253 Surface-Mounted Junction Box, IP65, 85 x 43 mm, Grey2TKA00005256 Surface-Mounted Junction Box, IP65, 85 x 43 mm, BlackThe square junction box AP10 (6.0 mm%u00b2, 500 V, IP65) is equipped abbwith 14 membrane cable entries (%u00d819 mm), three on each sides, and two in the bottom. Cables are easy to connect by simply inserting the stripped ends through the inlets. The box locks by snapping and can be opened by inserting a screwdriver into the opening slots - no screws are needed. The box can also be sealed. The box can be furnished with the strain-reliefs AS9.10, AS9, AS9.1 and AS9.3. Mounting temperature is -25... +60 %u00b0C. Made of halogen-free material (IEC/61249-2-21)Junction Box 104x104mm, IP65Part No. Description2TKA140002G1 Surface-Mounted Junction Box, IP65, 104 x 104 mm, White2TKA140003G1 Surface-Mounted Junction Box, IP65, 104 x 104 mm, Grey2TKA00004261 Surface-Mounted Junction Box, IP65, 104 x 104 mm, BlackThe square junction box AP9 (2.5 mm%u00b2, 500 V, IP65) is equipped with abb12 membrane cable entries (%u00d817 mm) in the sides, and two (%u00d819 mm) in the bottom. Cables are easy to connect by simply inserting the stripped ends through the inlets. The box locks by snapping and can be opened by inserting a screwdriver into the opening slots - no screws are needed. The box can also be sealed. The box can be furnished with the strain-reliefs AS9.10, AS9, AS9.1 and AS9.3. Fits %u00d86-15.5 mm cable. VDE-approved. Mounting temperature is -25... +60 %u00b0C. Made of halogen-free material (IEC/61249-2-21).Junction Box 86x86mm, IP65Part No. Description2TKA140012G1 Surface-Mounted Junction Box, IP65, 86 x 86 mm, White2TKA140014G1 Surface-Mounted Junction Box, IP65, 86 x 86 mm, Grey2TKA140013G1 Surface-Mounted Junction Box, IP65, 86 x 86 mm, Black2TKA00001564 Surface-Mounted Junction Box, IP65, 86 x 86 mm, Green2TKA00001563 Surface-Mounted Junction Box, IP65, 86 x 86 mm, Redabb Junction boxes AP9, AP10 and AP45 can be furnished with the strain-relief AS9.10 for 3 cables. AP9: 3x 6 - 17 mm. AP10: 1x 6 - 19 mm (middle) and 2x 6 - 12mm (sides). AP45: 3x 6 - 17 mm. It can also be used with 3 flexible connecting cables H03VVH2-F 2x0,75. Strain relief is done with help of cable tie (not included). Two strain-reliefs can be used in opposite sides the box with AP9 and AP10, or crosswise in AP9 boxes.Strain-Relief for 3 Cables, %u00d8 6%u201317 mmPart No. Description2TKA00003876 Strain-Relief for 3 Cables, %u00d86%u201317 mm
